Sai ovislink krypton c60 chasis 60 kva trifasico sin baterias

Capacity 10-200KVA

Main Input

Input voltage "380V/400V/415V(line to line)220V/230V /240V(line to neutral)"

Input frequency 50/60Hz

Power factor >,0.99

Input voltage window -40%~+25%

Frequency window 40-70HZ

Battery
Battery voltage ±240VDC

Charger power 20%*Power

Charger voltage precision 1%

Bypass
Bypass voltage "380V/400V/415V, three phase220V/230V/240V, one phase"

Bypass voltage window -20%-+15%, full load, settable

Bypass overload capabiltiy 125%, long time operation

125%<, load <,130%, last for more than 1 hour

130%

>,1000%, last for more than 100ms

Output
Output voltage "380V/400V/415V, three phase220V/230V/240V, one phase"

Voltage precision ±0.5% (balance load),±1% (unbalance load)

Voltage THD(Total Harmonic Distortion) THD<,1%(linear load),THD<,5%(nonlinear load)

Power factor 0.8

Phase tolerance 120°±0.5° (balance and unalance load)

Crest factor 3:1

Overload capabiltiy 105%,long time operation

110%, transfer to bypass after 1hour

125%, transfer to bypass after 10 minutes

150%, transfer to bypass after 1 minute

>,150%, transfer to bypass after 200ms

System
System efficiency Normal mode: 95%

ECO mode: 99%

Battery mode efficiency 95%

Display LCD+LED, Touch screen and keyboard

IP class IP20
Interface (Communication Ports ) RS232,RS485,Dry contacts,SNMP card,EPO,Generator
interface
Installation/Connection Top or bottom cable connection

Operation temperature 0-40

Storage temperature -25~70

Relative humidity 0-95% (non-comdensing)

Noise(dB) <,55dB
Weight(KG) 6-module cabinet RM060/10, RM090/15, RM120/20
150KG
10-module cabinet RM100/10, RM150/15, RM200/20
180KG
PM10 10KVA: 20KG

PM15 15KVA: 21KG

PM20 20KVA: 22KG

Dimension(W*D*H)(mm) 6-module cabinet 600*900*1600

10-module cabinet 600*900*2000

Module 400*600*133 (10KVA/15KVA/20KVA)
